Controller: Heidenhain
X =   1050
Y =    610
Z =    610

Table working surface: 1200 x 600 mm
Spindle nose to table: 100 – 710 mm
Spindle center to column: 640 mm
Spindle diameter: 65 mm
Spindle speed: 60-10000 rpm
Spindle motor: 15HP Hi-Lo Gear
X-Y-Z Rapid traverse: 30-30-20M/min
Cutting Feed: 1-12000 mm/min.
Tool selcetion: Bi-direction random type, Shortest path

BT40 / ATC 24
Adjacent pockets max. Tool dia.: 75 mm
Max. Tool length: 300 mm
Max. Tool weight: 10 kg.
Table load capacity: 1200 kg.

X-Y-Z Ball screw dia. Ø40, ø40, ø40

Cutting capacity S45C:
Milling (cm3/min): 180
Drilling (ømm): Ø40
Tapping (mm): M30XP3.5

Machine weight: 8500kg.
Floor space: 2920 x 3200 mm
